DTY單相智能固態調壓模塊用于三相負載,單向可控硅輸出。采用兩個可控硅混合動力技術,實現0-380伏無級調壓,提供高效熱量管理,并提高循環使用壽命。
特點● 過零觸發技術,干擾小,應用廣
● 電壓負載,體積小、速度快、壽命長
● 芯片與底板絕緣
● 控制輸入LED指示燈
● 輸出端采用可控硅,穩壓穩流
規格型號 | 負載電流 | 電機功率 | 控制信號 | 控制電流 | 介質電壓 | 通態壓降 | 斷態漏電流 | 正反轉切換時間 | 正反轉時間間隔 | 動作指示 | 工作環境溫度 | 規格書 |
JGX-3 DJ4810 | 10A | 1KW/380VAC | 3-32VDC | 5-25mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ | |
JGX-3 DJ4825 | 25A | 2.5KW/380VAC | 3-32VDC | 5-25mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ | |
JGX-3 DJ4840 | 40A | 4KW/380VAC | 3-32VDC | 5-25mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ | |
JGX-3 DJ4860 | 60A | 5.5KW/380VAC | 3-32VDC | 8-70mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ | |
JGX-3 DJ48100 | 100A | 10KW/380VAC | 3-32VDC | 8-70mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ | |
JGX-3 DJ48120 | 120A | 12KW/380VAC | 3-32VDC | 8-70mA | ≥2000V | ≤1.5VAC | ≤3mA | ≥0.05s | ≥50mS | 紅綠指示 | -40~80℃ |
